Eight - Head SMT Pick And Place Machine , 40000CPH Electric Feeder SMT Machine

40000CPH electric feeder 8 heads pick and place machine for LED bulb light and driver PCB

Machine description

Use the most convenient positioning block, base plate origin positioning method to fix position. The Positioning is highly accurate (Precision less than 0.05 mm). Mounting angle range 0-360° and the precision is 0.1°. Every picking nozzle is an independent rotation angle, moreover added 8 cameras for components recognition. In addition to place the traditional long led tube light, also can place bulb light, down light, spot light, ceiling light, LED fence light, LED driving power supply, copper wire string light and so on. All X, Y, W axis are equipped with imported precision ball bearing screw rods and guide rails. Z axis installed 8 sets of imported motor to drive, it enhanced the smooth coordination of equipment motion, reduced abnormal noise, greatly improved the placement accuracy and speed.

Product main features:

1. Mounting type: It can meet the mounting of SMD LED components of all specifications such as 0603 to 7272. In addition to all flat LEDs, other planar electronic components (such as resistors, capacitors, etc.) and high-power LEDs and lenses can be produced.

2, accurate positioning: the most convenient positioning block, substrate origin alignment, accurate positioning (accuracy less than 0.05mm). The mounting angle range is 0-360° with an accuracy of 0.1°. Each nozzle is a separate corner, plus six component recognition cameras, in addition to the traditional LED long strips, bulbs, down lights, spotlights, ceiling lamps, guardrail tubes, LED drive power, copper wire Light strings and the like can be mounted at will.

3, high precision: X, Y, W axis are equipped with imported precision ball screw and guide rail, Z-axis 8 groups of imported motor drive, enhance the smooth coordination of equipment movement, reduce abnormal noise, greatly improve the accuracy and speed of the patch.

4, the mounting plate specifications: platform 1200X300mm, suitable for 99% of the current LED products on the market;

Can be attached to various shapes of PCB board, without the need for fixtures, can be attached to the 1.2-1.5 meters long PCB board.

5. Vision system: Visual software online programming, in which the programming camera is a high-precision digital camera, without the need to manually input component coordinates; and the positioning method automatically recognized by the visual camera ensures the placement accuracy.

6, supporting software: the interface is simple and generous, functional and practical, visual software online programming, the software displays all the coordinate points in the imposition, and can fine-tune the coordinate points therein to achieve high-precision placement, no need to manually input component coordinates, fast and convenient Simple and clear, combined with the actual needs of many LED manufacturers to independently develop and design.

7, Yamaha Feida: The machine is equipped with 8 8MM Yamaha Feida (also optional Fuji Electric Feida), long service life, high stability and fast speed.

Technical parameters

Main Parts Supplier of machine

Placement product
