Product Details:
Payment & Shipping Terms:
|
| Product Name: | Used JUKI 2060 Smt Machine | Model: | JUKI KE-2060M |
|---|---|---|---|
| Applicable Components: | IC, BGA, TSOP, 0402 0603 0805 | Speed: | 13500 Chips/hour |
| Type: | SMT Machine Related Products | Function: | Welding Solder Paste |
| Highlight: | TSOP LED SMT machine,13500 chips/hour LED SMT machine |
||
Led smt machine Approx 1410kg JUKI KE-2060 Up to 80 types Other FX-1 FX-2 FX-3
JUKI KE-2060 Placement Machine SMT automatic production line equipment, JUKI placement machine KE2060 used JUKI chip mounter smt placement equipment
Shenzhen Wanbo High-tech Co., Ltd. has a JUKI senior engineer team with rich maintenance experience, specializing in providing JUKI series placement machine software and hardware maintenance and troubleshooting. It mainly includes JUKI laser head, CPU motherboard SUB-CPU board, drive board X/Y/Z/T axis driver, head board, image control card, I/O board, JUKI servo motor, camera, display touch screen, servo motor and other maintenance and replacement services. The company's fees are reasonable, the warehouse accessories are sufficient, the maintenance cycle is short, the one-time repair success rate is high, and the Pearl River Delta region can provide door-to-door installation, commissioning, maintenance and maintenance.
JUKI KE2060 SMT 12,500CPH: Chip (laser recognition / actual production ergonomics) 1,850CPH: IC (image recognition / actual production ergonomics), 3,400CPH: IC (image recognition / using MNVC) laser placement head × 1 (4 nozzles) & high-resolution visual mounting head × 1 (1 nozzle) 0603 chip (imperial 0201) chip ~ 33.5mm square element 0402 (imperial 01005) The chip is factory option image recognition (reflective/transparent recognition, ball recognition, segment recognition) ※Placement speed conditions may vary
JUKI2060 placement machine parameters:
Brand: JUKI made
Model: JUKI KE-2060
Placement head: 5
Material station: 80 types standard
Mounting speed:
0.25SEC/CHIP (3 heads are attached at the same time
MOUNTING ACCURACY: +/-0..05MM CHIP +/-0.05MM QFP(LASER)
MOUNTING RANGE: 1005—23.5MM (BY LASER)
PCB size: 510*360 *** small: 50*30
PCB thickness: 0.4-4MM
DIMENSIONS:1440*1393*1460 (INCLUDING SIGNAL LIGHT 2000MM)
Power supply: 3 phase AC220V 50/60 2.5KVA
Weight: 1420KG
JUKI 2060 modified placement inserting machine parameters:
| Substrate size |
M substrate (330×250mm) For L substrate (400×350mm) Ｌwide(510×360mm) E substrate (500×450mm) |
| Component size | 0603 chip (imperial 0201) chip ~ 20mm square element or 26.5×11mm (0402 (imperial 01005) |
| component height | 25mm |
| Component placement speed |
Component placement speed Chip components :12. 500CPH *3 IC components : 1.850CPH *3*4 / 3. 400CPH *5 |
| Component placement accuracy | Laser recognition ±0.05mm |
| Component placement type | Up to 80 types (converted to 8mm belt.) |
| Device size*2(W×D×H*3) | 1,400×1,393×1,450mm |
| Weight: | Approx. 1,410kg |
The JUKI KE-2060/2060L can be modified with mature technology and can insert various special-shaped components, capacitors, etc.
JUKI KE-2060 multi-function all-in-one plug-in placement machine JUKI high-precision special-shaped component placement machine rental and sale
Other new and used JUKI smt machine models:
KE740 KE750 KE760
JUKI KE-2000 KE2010 KE2020
JUKI KE-2050 KE2060 KE2070 JUKI KE-2080
FX-1R FX-2 FX-3L
JX-100LED JX-300LED JX-350
JUKI SMT machine Accessories include: all kinds of original, domestic nozzles, FEEDER, boards, lasers, solenoid valves, inductors, cylinders, tank chains, etc.), laser maintenance, board maintenance and so on
Other models of new or used JUKI SMT placement machines:
all spare parts of Juki smt machine can provide.
