Offline Machine AOI SZ-X3 Post Welding Electronic Board Short Circuit Check


The function of AOI testing equipment is to detect PCBA board control defective products.
After the wave soldering of the DIP plug-in: more tin, less tin, tin hole, short circuit, pin not out, etc.
After SMT furnace: missing parts, misalignment, wrong parts, polarity reverse, breakage, pollution, less tin, more tin, short circuit, virtual soldering, etc.
Equipment separation line machine and online machine.
Offline models: X1 detection patch products, X3 detection plug-in products;
Online models: X5 camera photo detection patch products, X6 camera photo detection plug-in products.

Shenzhen Wanbo Hi-Tech Co., Ltd. is a professional electronic equipment manufacturer integrating R&D, production and sales.
1. Production: AOI testing equipment, AI plug-in machine, wave soldering, reflow soldering, connection platform, automatic loading and unloading machine, stacking machine, corner machine and other equipment;
2. The warehouse has second-hand equipment: Panasonic placement machine, Yamaha placement machine, JUKI placement machine, Samsung placement machine, domestic EZ-Link placement machine, domestic platform machine placement machine,
Printing machine, reflow soldering and other supporting equipment; The warehouse has accessories: motors, boards, laser heads, accessories FEEDER, nozzles, etc.

Shenzhen Wanbo Hi-Tech Co., Ltd. has invested millions of yuan in the maintenance business department, purchased advanced maintenance equipment and instruments from abroad, and can carry out disassembly-free online testing of the quality of various control board ICs. Equipped with various programmers, various PROM, EEPROM, PLD, MCU and other programmable ICs to download, program, copy, decrypt, encryption, etc. It has advanced laser special testing and debugging instruments and equipment. And self-developed and designed dozens of simulation test fixtures. The repaired parts can be quickly repaired, replaced and discounted.

Panasonic Panasonic full range of placement machines:
1. Panasonic Panasonic CM series placement machine model: CM88 CM202 CM212 CM 402 CM602;
2. Panasonic Panasonic BM series placement machine model: BM123 BM133 BM221 BM231;
3. Panasonic Panasonic NPM series placement machine models: NPM-D1, NPM-D2, NPM-D3, NPM-D1, NPM-W, NPM-W2;
Other Panasonic placement machine models are: mv2c mv2f mv2v mv2vb msh mpa msr msf and so on
CM BM has been discontinued. The big plate Panasonic is a product of the last century . Except that MSR HT MSF MCF is a product of the beginning of this century.
Now the mainstream is the NPM series: D, D3, D3A, DX, W, W2, WX, WXS, TT, TT2, VM101, VM102, AM100
Panasonic placement machine models include NPM, DT-401F, CM602, CM401, CM202DH, NPM-D3, CM301-D.

Device parameters and configuration


Tip: The missing frame of the resistor is the same detection frame as the wrong part frame, which mainly detects silk screening.
