Product name: LED pick and place machine S6 speed 25000CPH-38000CPH

High speed pick and place machine 6 heads 25000CPH of bulb light electronic feeder 0High speed pick and place machine 6 heads 25000CPH of bulb light electronic feeder 2High speed pick and place machine 6 heads 25000CPH of bulb light electronic feeder 4High speed pick and place machine 6 heads 25000CPH of bulb light electronic feeder 6

High speed pick and place machine 6 heads 25000CPH of bulb light electronic feeder 8



Product main features:


1. The platform USES the Japanese panasonic servo motor, imported orbit, ensure the stability and control precision of mobile platform.
2. The X, Y axis adopt panasonic servo drive, with imported linear guide, ensure the patch of high precision, high speed, the stability of the first-class.
3. 4 sets high speed post opening work at the same time, greatly improve the equipment performance. Under the suction head adopt the imported guide rail, high precision and long durability.
4. Easy to understand way of graphical programming, greatly improve the convenience of operation, automatic visual auxiliary positioning positioning, accurate, convenient.
5. The selection of a variety of batcher, can satisfy the requirement of different LED packaging components of SMT.
6. Controlled by industrial control computer + independent special controller, system stability, simple operation, easy to learn.
7. Powerful software, programming coordinates using numerical and graphical display, coordinate correction and change is convenient, the production process of graphical display patch progress and components, subsidy is convenient.
8. The software USES the database system, different types of PCB programming can be stored, convenient call, a programming of new products, calling for life.
9. The platform, the Y axis, the X axis can be manually move, free movement speed adjustment, realize arbitrary point can manually to arrive, convenient programming.
10. Imported negative pressure detection system, to accurate detection of absorption material, effectively prevent leakage of material, extractor.
11. A negative pressure generator with built-in, low noise, long service life, vacuum pressure constant.
12. The standard configuration: 1 set of industrial control computer, opening four groups, suction nozzle 12;

13. Optional: matchs outside to 8 mm, 12 mm, 16 mm and 24 mm yamaha feeder; Air compressor;

High speed pick and place machine 6 heads 25000CPH of bulb light electronic feeder 10





Technical parameters:



Technical parameters

Product name

SST full automatic 1.5m pick and place machine SST-S6

Maximum PCB area

1200×380mm

Maximum moving range



X axis 1200mm, Y axis 390mm

Z axis Maximum moving range

12mm

Max placement speed

45000CPH

Typical placement speed

0-35000CPH



Movement precision

±0.05mm



Positioning method



MARK point camera + visual camera position



Can mount components



0603 upper resistor and capacitor, and all kinds LED 3528, 7070 LED chips, meanwhile meet requirement of SOP SOT chip placement, and compatible with all kinds of high power chip mount.



Types of production



LED tube light,soft LED strip light,power supply driver,fence light,display module,display screen etc multi LED application products



Programming method



Automatic Visual camera Positioning programming



Belt type feeder



8mm, 12mm, 16mm, and 24mm feeder



Number of feeders



14pcs of standard 8mm feeder or 7pcs of 12mm feeders can be installed



Operating system

WINDOWS 7



Compressed air

0.55MPA



Power supply

220V, 50Hz, 2.0KW



Weight

1200Kg



Dimension

2000MM(L)*1200MM(W)*1450MM(H)







High speed pick and place machine 6 heads 25000CPH of bulb light electronic feeder 12





1, Mount: Mount 0603 to 7272 can meet all specifications of SMD LED components. In addition to all the planar LED plane, other electronic components (such as resistors, capacitors) and high power LED and the lens can be produced.



2, precise positioning: positioning block is the most convenient way to position the substrate, the origin of counterpoint, accurate positioning (accuracy less than 0.05mm). Mount angle range of 0-360 degrees, the accuracy of 0.1 degrees. Each suction nozzle is independent of angle, and six element recognition cameras, in addition to LED lamp can mount the traditional., bulb lamp, lamp, lamp, ceiling lamp, guardrail tube, LED drive power, copper lamp series and so on can be freely mounted.



3, high precision: X, Y, W axis are equipped with precision ball screw and guide rail, Z axis 6 sets of imported motor drive, enhance the smooth coordination of equipment movement, reduce abnormal noise, greatly improve the accuracy and speed of the patch.



4, SMT specifications: platform 1200X310mm, applicable to the current market of 99% LED products;

PCB board can be affixed to various shapes, without clamps, can be affixed 1.2-1.5 meters long PCB board



5, the visual system, visual programming software online programming, which is of high precision digital camera camera, there is no need to manually input elements and positioning coordinates; using visual camera automatic identification, to ensure the accuracy of mount.



6: the software interface is simple and elegant, functional and practical, visual software online programming, display all coordinates in the imposition software, and fine-tuning of the coordinates of the point, in order to achieve high precision mount, without manual input element coordinates, fast and convenient, simple and clear, combined with the actual needs of many LED manufacturers R & D design.



7, YAMAHA Feeder: machine configuration 6pcs 8MM YAMAHA Feida (also optional with Fuji electric Feida), long service life, high stability, fast speed
