Mini Selective Wave Soldering Machine Durable For SMT Production Line

I'm Online Chat Now

Mini Selective Wave Soldering Machine Durable For SMT Production Line

China Mini Selective Wave Soldering Machine Durable For SMT Production Line supplier
Mini Selective Wave Soldering Machine Durable For SMT Production Line supplier Mini Selective Wave Soldering Machine Durable For SMT Production Line supplier Mini Selective Wave Soldering Machine Durable For SMT Production Line supplier Mini Selective Wave Soldering Machine Durable For SMT Production Line supplier Mini Selective Wave Soldering Machine Durable For SMT Production Line supplier Mini Selective Wave Soldering Machine Durable For SMT Production Line supplier

Large Image :  Mini Selective Wave Soldering Machine Durable For SMT Production Line

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: WANBOSST
Certification: CE

Payment & Shipping Terms:

Minimum Order Quantity: 1 Piece/Pieces
Price: discuss price
Packaging Details: Wooden box package
Supply Ability: 1000 Piece/Pieces per Month Mini Selective Wave Soldering Machine
Contact Now
Detailed Product Description
Type: Soldering Machine Condition: New
Rated Duty Cycle: Other Rated Capacity: Other
Voltage: 380V Current: Other
Dimensions: 3650*1200*1650mm Weight: 850KG, 1500KG
Usage: DIP Wave Soldering Product Name: Mini Selective Wave Soldering Machine
Customize: Yes Solder Volume: 350kg
Solder Temperature: 350 Degree Temperature Control: PC+PID
PCB Conveyor Direction: 760mm PCB Width: 350mm
Preheating Zone Number: 3 Stages Power Supply: 380V
After-sales Service Provided: Engineers Available To Service Machinery Overseas Port: Shenzhen

Mini Selective Wave Soldering Machine Durable For SMT Production Line

Assembly Line Mini Selective Wave Soldering Machine

Mini Selective Wave Soldering Machine Durable For SMT Production Line

Mini Selective Wave Soldering Machine

Product Features:


1. Body linear design, using spray technology, beautiful and durable.
2. Three separate 1.5 m preheating section, all hot air preheating, with spotlights compensation device, the PCB to get a good welding results.
3. Patent-type titanium alloy die-cast claw chain, non-stick tin, never deformation, long life.
4. Throughout the observation window for easy operation and maintenance.
5. Tin stove down and out, with auto and manual adjustment. The use of back design to prevent misuse damage the machine.
6. Equipped with a cooling module, the temperature compensation module, suitable for lead-free solder and a variety of process requirements.
7. The latest invention of ultra-smooth, ultra filtered source generator, significantly weakened the flow of shock flow and turbulence within the tin production, tin wave stable, oxidation is greatly reduced, maintenance is simple.
8. Modular design with precision drive mechanism, drive accurate, long life, easy maintenance.
9. Rosin spray device can be pulled out, and removable, easy to clean and maintain.
10. Isolated spray device, flux fumes from the exhaust air duct dedicated.
11. Powerful library function parameters, various types of PCB process parameters can be invoked on demand operating.
12. A professional industrial computer control system to ensure reliability and stability.
13. The user can set the date, time and temperature parameters for Automatic Switcher.
14. Self-diagnosis system failure, malfunction automatically, troubleshooting queries at any time.
15. Heating temperature using PID closed-loop control, temperature control is stable and reliable.
16. Automatic tracking loop spray system, spray width and spray time to adjust, and spray as needed to extend the time set in advance and.
17. Over automatically from the wave plate, to minimize the amount of tin oxide.
18. Transport system with force limiters + limiting clutch double protection device.
19. Short circuit and overcurrent protection system.
20. Transportation system closed-loop control. Variable speed, precise control of PCB preheating and welding time.



Industrial PC control system dual wave soldering equipment, in addition to the usual machine-compatible automation performance, the more streamlined body design, simple and convenient computer window system, automated production and management of records to the next level.



Product parameters:

PCB Working width Max. 300mm
PCB conveyor direction 760±10mm
PCB conveyor speed 0-2.0m/min
Preheating zone length 1500mm
Preheating zone number 3 stages
Preheating temperature 0~250℃
Solder volume 200-300KG Can be customized
Solder temperature 0~350℃
Temperature control type PC+PID
Flux storage tank Max5.2L
Power AC380V
Power for heating up 20KW
Power for operation 7KW
Air supply 4-7kg/cm2 12.5L/min
Weight 850KG
Dimensions(L*W*H) 3650*1200*1650mm



Product main features:


1. The platform USES the Japanese panasonic servo motor, imported orbit, ensure the stability and control precision of mobile platform.
2. The X, Y axis adopt panasonic servo drive, with imported linear guide, ensure the patch of high precision, high speed, the stability of the first-class.
3. 4 sets high speed post opening work at the same time, greatly improve the equipment performance. Under the suction head adopt the imported guide rail, high precision and long durability.
4. Easy to understand way of graphical programming, greatly improve the convenience of operation, automatic visual auxiliary positioning positioning, accurate, convenient.
5. The selection of a variety of batcher, can satisfy the requirement of different LED packaging components of SMT.
6. Controlled by industrial control computer + independent special controller, system stability, simple operation, easy to learn.
7. Powerful software, programming coordinates using numerical and graphical display, coordinate correction and change is convenient, the production process of graphical display patch progress and components, subsidy is convenient.
8. The software USES the database system, different types of PCB programming can be stored, convenient call, a programming of new products, calling for life.
9. The platform, the Y axis, the X axis can be manually move, free movement speed adjustment, realize arbitrary point can manually to arrive, convenient programming.
10. Imported negative pressure detection system, to accurate detection of absorption material, effectively prevent leakage of material, extractor.
11. A negative pressure generator with built-in, low noise, long service life, vacuum pressure constant.
12. The standard configuration: 1 set of industrial control computer, opening four groups, suction nozzle 12;
13. Optional: matchs outside to 8 mm, 12 mm, 16 mm and 24 mm yamaha feeder; Air compressor.



Technical parameters:

Machine Model

WANBO SST-S6LV

The biggest circuit board area

1200×380mm

Maximum moving range

X axis 1220mm, Y axis 430mm

Z axis Maximum moving range

12mm

Typical patch speed

30000cph-35000cph

Typical LED lens patch speed

6000cph-15000cph

The theory of maximum patch speed

50000cph

positionaI accuracy

±0.05mm

Location way

Mark point camera + Visual camera positioning

Components can be placed

0603 above to 7272 resistors and capacitors, and all kinds of 0603 and 3528, 5050, 5630, 5730, meet placement of SOP SOT chip, and compatible with all kinds of high-power chip SMD componets, LED lens placement

Programm method

Computer graphical programming + visual camera positioning

Feeder applicable

8mm, 12mm, 16mm and 24 belt type feeder, or vibration plate

Number of feeder

Standard placed 18pcs feeders of 8mm or 12mm, or 2pcs 4 channels vibration plate

nozzles

JUKI nozzle 504, 505 and 506

Product

LED fluorescent tube, soft light belt, power drive, guardrail tube, module, display and other LED applications

operating system

WINDOWS XP, WIN 7

negative pressure

An external air source 0.55MPA

Power and rate

220V, 50Hz, 1.2KW

Weight

1200Kg

Dimension

2000MM(L)*1050MM(W)*1400MM(H)


Mini Selective Wave Soldering Machine Durable For SMT Production Line



Mini Selective Wave Soldering Machine Durable For SMT Production Line
