Economical Electric Feeder Machine , 8 Heads LED Pick And Place Machine

Economical Electric Feeder Machine , 8 Heads LED Pick And Place Machine

Economical Electric Feeder Machine , 8 Heads LED Pick And Place Machine
Economical Electric Feeder Machine , 8 Heads LED Pick And Place Machine Economical Electric Feeder Machine , 8 Heads LED Pick And Place Machine Economical Electric Feeder Machine , 8 Heads LED Pick And Place Machine Economical Electric Feeder Machine , 8 Heads LED Pick And Place Machine

Large Image :  Economical Electric Feeder Machine , 8 Heads LED Pick And Place Machine Get Best Price

Product Details:
Place of Origin: China
Brand Name: WANBO SST
Model Number: S8
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: discuss price
Packaging Details: wooden box package, 2200*1300*1600mm, 1200kg-2500kg
Payment Terms: L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100pcs per month
Detailed Product Description
Product Name: Pick And Place Machine Heads: 6/8 Heads
Motor: Servo Motor Speed: 25000-30000CPH
Precision: 0.05mm Feeder: 16pcs Of 8mm Feeders
Weight: 1200kg Power Supply: AC 220V
Make Products: Bulb Light, Tube Light, Panel Light, Flood Light, Driver Customize: Yes
High Light:

smt assembly equipment

,

smt pick and place machine

Economical electric feeder 8 heads smt pick and place machine for LED bulb tube driver





Product name: pick and place machine S8 complete SMT line

1.2 meter screen printer + S8 pick and place machine  +  6/8 zones reflow oven



Economical Electric Feeder Machine , 8 Heads LED Pick And Place Machine 0

Product main features:


1. The platform USES the Japanese panasonic servo motor, imported orbit, ensure the stability and control precision of mobile platform.
2. The X, Y axis adopt panasonic servo drive, with imported linear guide, ensure the patch of high precision, high speed, the stability of the first-class.
3. 4 sets high speed post opening work at the same time, greatly improve the equipment performance. Under the suction head adopt the imported guide rail, high precision and long durability.
4. Easy to understand way of graphical programming, greatly improve the convenience of operation, automatic visual auxiliary positioning positioning, accurate, convenient.
5. The selection of a variety of batcher, can satisfy the requirement of different LED packaging components of SMT.
6. Controlled by industrial control computer + independent special controller, system stability, simple operation, easy to learn.
7. Powerful software, programming coordinates using numerical and graphical display, coordinate correction and change is convenient, the production process of graphical display patch progress and components, subsidy is convenient.
8. The software USES the database system, different types of PCB programming can be stored, convenient call, a programming of new products, calling for life.
9. The platform, the Y axis, the X axis can be manually move, free movement speed adjustment, realize arbitrary point can manually to arrive, convenient programming.
10. Imported negative pressure detection system, to accurate detection of absorption material, effectively prevent leakage of material, extractor.
11. A negative pressure generator with built-in, low noise, long service life, vacuum pressure constant.
12. The standard configuration: 1 set of industrial control computer, opening four groups, suction nozzle 12;

13. Optional: matchs outside to 8 mm, 12 mm, 16 mm and 24 mm yamaha feeder; Air compressor;



Technical parameters



Product name

SST 1.5m pick and place machine SST-S6/S8

Maximum PCB area

1200×285mm

Maximum moving range

X axis 1200mm,Y axis 320mm

Z axis Maximum moving range

12mm

Max placement speed

38000CPH

Typical placement speed

25000-35000CPH

Movement precision

±0.05mm

Positioning method

MARK point camera + visual camera position

Can mount components

0603 upper resistor and capacitor parts and LED chips 3528, 5050, meanwhile meet requirement of SOP SOT chip placement, and compatible with all kinds of high power chip mount.

Types of production

LED tube light,soft LED strip light,power supply driver,fence light,display module,display screen etc multi LED application products.

Programming method

Automatic Visual camera Positioning programming

Belt type feeder

8mm, 12mm, 16mm, and 24mm feeder

Number of feeders

20pcs of standard 8mm feeder or 10pcs of 12mm feeders can be installed

Operating system

WINDOWS 7

Compressed air

0.55MPA

Power supply

220V,50Hz,2.0KW

Weight

1200Kg

Dimension

2000MM(L)*1100MM(W)*1450MM(H)




Main Parts Supplier of machine



Cables Germany IGUS
Servo motor PANASONIC
Screw rod Japanses KURODA/THK
Guide rail Taiwan HIWIN
Vacuum system Germany vacuum pump
Head Z motor Japan Shino
Inductive switch Panasonic
Negative pressure meter Panasonic
Camera Sony





Placement product



Economical Electric Feeder Machine , 8 Heads LED Pick And Place Machine 1

Economical Electric Feeder Machine , 8 Heads LED Pick And Place Machine 2

Economical Electric Feeder Machine , 8 Heads LED Pick And Place Machine 3

Economical Electric Feeder Machine , 8 Heads LED Pick And Place Machine 4

Contact Details
Shenzhen Wanbo Hi-Tech Co., Ltd.

Contact Person: Mr. Su Zhongqiu

Tel: 008613172493285

Fax: 86-755-33940745

Send your inquiry directly to us
