Single Station Circular Glue Dispenser Machine For Bulb Light / Speaker Cover

I'm Online Chat Now

Single Station Circular Glue Dispenser Machine For Bulb Light / Speaker Cover

China Single Station Circular Glue Dispenser Machine For Bulb Light / Speaker Cover supplier
Single Station Circular Glue Dispenser Machine For Bulb Light / Speaker Cover supplier Single Station Circular Glue Dispenser Machine For Bulb Light / Speaker Cover supplier Single Station Circular Glue Dispenser Machine For Bulb Light / Speaker Cover supplier Single Station Circular Glue Dispenser Machine For Bulb Light / Speaker Cover supplier

Large Image :  Single Station Circular Glue Dispenser Machine For Bulb Light / Speaker Cover

Product Details:

Place of Origin: CHINA
Brand Name: WANBO
Model Number: BL-10

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: discuss price
Packaging Details: wooden box package
Supply Ability: 100pcs/month
Contact Now
Detailed Product Description
Product Name: Glue Dispenser Equipment Structure: Cabinet Structure
Driver Motor: Stepper Motor + Timing Belt + Linear Guide Mechanical Hand: Precision Robot
Air Pressure: 0.2-0.7MPA Control Voltage: 24v
Max Speed: 500mm/s Positioning Accuracy: 0.01mm
Status: New Weight: 33kg

Single station circular glue dispensing machine, bulb light and speaker cover dispensing machine





BL-80 glue dispenser



LED bulb light glue dispensing machine





Single station circular dispensing machine, LED flying saucer dispensing machine, speaker cover dispensing machine non-standard custom



product description:



◎ Self-developed dispensing system software, the operation interface is simple, user-friendly and easy to master.



◎ One device can replace 3 to 5 labors, and the production capacity is greatly improved.



◎ High product consistency, saving glue, no need for trimming of finished products.



◎ The workshop environment is improved and the customer's factory satisfaction is improved.



Features:



1. The material used for the casing is 3mm thick cold-rolled plate, 8mm thick aluminum panel, firm and solid, and the appearance is beautiful and generous;



2. It adopts industrial PLC and text controller control, which is easy to operate and humanized;



3. precision stepper motor drive, reciprocating motion is accurate and reliable;



4. The gas path parts are all controlled by imported pneumatic components, with fast response and long service life;



5, the unique rotary valve design, the glue is quick, the glue is clean, and the wire is not drawn;



6, the program can be set to round the glue.



7, hand wheel + slider design, adjustment and positioning is more convenient and convenient;



9. Optional increase of UV glue glue function;



Product Specifications:





Equipment type BL-10
Body parameters
Dimensions: L450mm*W400mm*H750mm
Machine weight: 33Kg
control parameter
Control method: industrial PLC
Programming mode: text demonstration programmer
Drive mode: precision stepper motor
Maximum dispensing diameter: 500mm
Motor speed: 0 ~ 300 rev / min
Positioning accuracy: ±0.1mm
Z axis adjustment mode: trapezoidal screw
Z axis adjustment range: 250mm
Z axis travel: 30mm
Environmental requirements
Working power: AC220V/50~60Hz/200W
Working pressure: 0.4~0.6Mpa (anhydrous mist)
Working temperature: room temperature
Applicable Products: LED industrial and mining lamps, PAR lights, garden lights, round panel lights, hot plates at the bottom of hot water bottles, motors, etc.

Applicable glue:



Glass glue, silicone glue, silicone rubber, red glue, yellow glue, silver paste, UV curing glue, silicone resin, UV shadowless glue, two-component epoxy resin, etc.
