Enter Component Standard Production:smt pick and place machine
５. Standard registration and debugging
5.1 capacitance
Capacitors, the most common components in PCBA after furnaces,pick place machine
do not have polarity. The component standard of capacitors includes 1 body frame,
2 low tin frames, 2 blank solder frames, 2 missing parts frames, and 1 wrong part frame.

The schematic diagram of its component registration is as follows:smd pick and place machine
In the figure above, the red box is the body frame, the yellow box is the wrong part frame,
the blue box is the less tin frame (empty soldering frame and missing part frame),
and the position of the less tin frame is basically the same as the empty soldering frame and missing part frame.
Its registration form is as follows:smd assembly machine

As shown in Figure (1) above, all the detection items for capacitance.
Its registration and debugging are as follows:pick n place machine

5.2. resistance
Resistance, which is a more common component in PCBA after the furnace, does not have polarity.
The resistor registration standard includes 1 body frame, 2 less tin frames, 2 empty solder frames,
and 1 wrong part (missing parts) frame. The schematic diagram of its component registration is as follows:

See the figure above, the red box is the body frame, the yellow box is the wrong part (missing parts) box,
the blue box is the less tin frame (empty soldering frame),
and the position of the less tin frame and the empty solder frame and the missing part frame are basically the same.
Its registration form is as follows:
