Yamaha YS10 SMT automated optical inspection equipment Detects Mobile Phone Charger Power Strip


The function of AOI testing equipment is to detect PCBA board control defective products.
After the wave soldering of the DIP plug-in: more tin, less tin, tin hole, short circuit, pin not out, etc.
After SMT furnace: missing parts, misalignment, wrong parts, polarity reverse, breakage, pollution, less tin, more tin, short circuit, virtual soldering, etc.
Equipment separation line machine and online machine.
Offline models: X1 detection patch products, X3 detection plug-in products;
Online models: X5 camera photo detection patch products, X6 camera photo detection plug-in products.

Tokyo Heavy Machinery is one of the important overseas subsidiaries of the JUKI Group, which was established in December 1994 in Shanghai, China, mainly engaged in the sales of JUKI placement machines.
Technical support, repair and maintenance. JUKI manufactures the placement equipment division, entered the field of placement equipment in 1987, and in 1987 JUKI developed the KP series of small universal placement machines.
KP-560, KP-620, KE-710/720 series (mechanical positioning) launched in 1993, KE-730/740 series (laser positioning) in 1995,
In 1997, KE-750/760 series placement machine was launched, KD-2077 was launched in 1998, and JUKI officially opened the era of medium-speed machines from 2000 to 2009.
In 2000, KE-2000 series was launched, high-speed placement machine KE-2010, high-speed universal placement machine KE-2020; 2001 high-speed placement machine KE-2030
. 2003 high-speed placement machine KE-2050, high-speed universal placement machine KE-2060; 2004 High Speed Module Placement Machine FX-1;

2005 new generation universal press CX-1; In 2007, JUKI ace placement machine was born, high-speed placement machine KE-2070, high-speed universal placement machine KE-2080;
2008 High-speed dispenser KD-2077, high-speed module mounter FX-2, high-speed module mounter FX-3;
2010-2017 JUKI entered the SMT line combination program
In 2010, the placement machine JX-100LED was entered, in 2011, the universal placement machine JX-200, the high-speed placement machine KE-3010, the high-speed universal placement machine KE-3020,
High Speed Module Mounter FX-3R; 2013 LED placement machine JX-300LED, multitasking platform JM-20; 2014 High Speed Compact Module Placement Machine RX-6,
Substrate visual inspection machine RV-1; In 2016, JUKI high-performance module machine was born, and RX series high-speed compact module placement machine RX-7 was launched, high-speed compact module
Mounter RX-6R, High Speed Extension Mounter JX-350, Paste Solder Printing Machine RP-1, Substrate Visual Inspection Machine RV-2, 2017 Best Selling King RS-1 Born!
High speed intelligent module placement machine RS-1;
March 2019 high-speed intelligent module placement machine RS-1R, high-speed intelligent module placement machine RX-7R
The classic models of JUKI placement machines are as follows:
FX-1 FX-3 FX-3R KE-750 KE-760 KE-2010 KE-2020 KE-2030 KE-2050 KE-2060
KE-2070 KE-2080 RX-6 RX-
7 FX-3RL FX-2 KE-3010 KE-3020 JX-100 JX-200 JX-30OLED JX-35OLED RS-1 RS-1R RX-7R JM-10 JM-20 JM-100；
JUKI full range placement machine KJ series
KE series KE-730/750/760, KE-2010/2020/2030/2050/2060/2070/2080 KE-3010/3020
FX series FX-1/ FX-2/ FX-3 are high-speed machines
RX-6 RX-7 FX-3RL
JX series LED special placement machine JX-100 JX-200 JX-300LED JX-350LED
KD-2077 High Speed Smart Placement Machine RS-1
JUKI KJ-01 KJ-02 KJ01 KJ02
Device parameters and configuration


Tip: The missing frame of the resistor is the same detection frame as the wrong part frame, which mainly detects silk screening.
